Putty & Gypsum Sprayer BU N1

Get a Price/Quote

MOQ : 1 , , Piece

Putty & Gypsum Sprayer BU N1 Specification

Type
Putty & Gypsum Sprayer

Material
Metal Body with Engineering Polymer Parts

Capacity
40 Liters/Hopper

Computerized
No

Automatic Grade
Semi-Automatic

Control System
Manual/Hand-operated Valve

Drive Type
Pneumatic (Air Compressor Driven)

Voltage
220 V (for compressor, if applicable)

Power
Not Applicable (manual sprayer, except air compressor)

Weight (kg)
12 Kg (Approx)

Dimension (L*W*H)
600 mm x 350 mm x 800 mm (Approx)

Color
Silver with Red & Black Accents

Spraying Distance
300 - 500 mm from Surface

Hopper Material
Heavy-Duty Metal

Recommended Compressor Output
2 HP or above

Spray Output
Up to 450 Sqft/hr (Depending on material and operator skill)

Usage
Interior & Exterior Wall Finishing

Application
Suitable for Spray Application of Putty, Gypsum, Cement Mortar, POP, and Texture Coating

Handle Type
Ergonomically Designed Grip

Surface Finish
Powder Coated

Air Consumption
250 - 350 L/min

Nozzle Size
4 Nozzles, 6-8 mm

Putty & Gypsum Sprayer BU N1 Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
500 Pieces Per Day

Delivery Time
3-7 Days

About Putty & Gypsum Sprayer BU N1

Putty & Gypsum Sprayer BU N1 is a high performance industrial machine which is used to apply coating of gypsum on the concrete structures to provide a smooth texture. The machine consist of a mixing area which is known as hopper where all of the mixing of dry raw materials take place. Putty & Gypsum Sprayer BU N1 is equipped with two heavy duty motors one is used in hopper for the mixing of raw material and another for the pumping of the fine mixture through a nozzle. It is operated using a 220 to 240 volt AC supply. The complete setup is supported on four castor wheels to easily move it to the required place with minimum force. It has a spraying capacity of 10000 to 15000 square feet per day.

Type of Current ( V/Hz)	220-240V / 50 Hz
Motor Power	1000 W / 1.4 HP
Conveying Pressure	20 Bar
Conveying Height	3-15 m
Connected Pipe	40 ft
Hopper Capacitance	40 Ltr
Nozzle Cobber	3,4,6 mm
Gross Weight	40 Kgs
Spraying Capacity	10,000 - 15,000 Sq. Ft /day, depends upon the Labour Skill
Warranty	One year for the Motor & Six months for the Compressor

High Efficiency and Versatile Performance

Delivering up to 450 Sqft/hr, the BU N1 Putty & Gypsum Sprayer is engineered to handle a wide range of wall-finishing materials. Its compatibility with gypsum, putty, POP, cement mortars, and textured coatings makes it an essential asset for contractors, decorators, and wall-finishing specialists.

User-Friendly and Ergonomic Design

Featuring an ergonomically designed grip and a robust, powder-coated metal body, this sprayer ensures comfortable use over extended periods. The 40-liter hopper and efficient manual valve controls allow for uninterrupted spraying, boosting productivity for interior and exterior wall projects.

Durable Construction for Professional Use

Built with heavy-duty metal and precision engineering polymer parts, the BU N1 withstands the rigors of demanding worksites. Its powder-coated finish resists corrosion, ensuring longevity, while the pneumatic operation provides consistent results with minimal maintenance.

FAQs of Putty & Gypsum Sprayer BU N1:

Q: How do I operate the Putty & Gypsum Sprayer BU N1?

A: To operate the BU N1, connect it to an air compressor with at least 2 HP output and a minimum air consumption of 250350 L/min. Fill the 40-liter hopper with your chosen material, set the appropriate nozzle size (68 mm), and maintain a spraying distance of 300500 mm from the wall. Control the spray output using the manual valve for even application.

Q: What materials can be applied using this sprayer?

A: This sprayer is suitable for spray applications of wall putty, gypsum plaster, cement mortar, POP (plaster of Paris), and a variety of texture coatings. Its versatile nozzles and ergonomic design make it ideal for achieving smooth and textured finishes on interior or exterior walls.

Q: When should I use the BU N1 sprayer compared to manual applications?

A: The BU N1 is recommended when you need to cover large surface areas quickly and efficiently, as it delivers up to 450 Sqft/hr. It significantly reduces manual labor time, provides a more uniform finish, and is perfect for use in construction, renovation, or decorative wall projects.

Q: Where can the Putty & Gypsum Sprayer BU N1 be used?

A: This sprayer is designed for both interior and exterior wall finishing. It can be used in residential, commercial, or industrial settings where putty, gypsum, or texture material needs even application over extensive wall surfaces.

Q: What is the process for setting up the BU N1 for spraying?

A: Begin by ensuring your air compressor meets the recommended output. Attach the sprayers pneumatic hose, fill the hopper with the desired material, choose the appropriate nozzle, and adjust your spraying distance to 300500 mm. Use the manual valve to regulate flow and ensure an even coat during application.

Q: What benefits does this sprayer offer professionals and contractors?

A: The BU N1 sprayer increases efficiency by covering large wall areas quickly, offers versatility for multiple materials, and ensures a consistent, high-quality finish. Its durable construction and ergonomic design reduce operator fatigue, making it an excellent investment for professionals.
